無塵自動循環回收噴砂機系列

◆廠品優點和缺點 Product features（請從上到下預覽大量例美圖照片供基準）

環保型循環回收式噴砂機它集噴砂、回收、循環、分離、除塵于一體，無污染及砂料四處飛揚現象，是新一代的環保型噴砂設備。是我公司為繁重的噴砂工作設計生產的多用途、大工作半徑、高效率的新型環保噴砂設備。根椐負壓產生裝置不同，分為電動和全氣動兩大種機型。該設備采用壓縮空氣做動力，將磨料高速噴射到工件表面，經過磨料沖擊把工件表面銹污除去，使表面達到一定的清潔度和粗糙度，再通過真空泵（或多級真空發生器）產生的負壓，回收砂料和粉塵，并通過設備的砂塵分離系統將完整的磨料分離繼續循環使用，粉塵與銹污進入集塵桶。在手把開關控制下，設備的噴砂、回砂、砂塵分離、砂料循環、粉塵過濾等所有動作自行完成，工作環境干凈無污染，作業現場達到“GB103328-10333-89”廠區水汽塵土安全標準單位。砂料、塵土重新出售、離心分離、循環系統施用，操作活動現場干凈整潔無塵土空氣污染。生產設備節能減排規劃，在很大程度上緩和了操作人員的勞動就業的強度和操作生態環境搭配除塵器原理部件，可控制系統自然移除濾清器靜電。自帶分水過濾裝置器。可對再壓縮大氣做出二級油和水脫離。控制系統自然放料，將吸砂頭插入表格砂料中，發動渦流泵控制系統將控制系統自然放料。PLC可程序語言控住（配搭），料位報警器技能(選型)。存在調壓開關按鈕、反吹風開關按鈕。穩定性高的氣控安裝與金剛石工具閥。作業圓的直徑20-70米，表層凈化處理登級達Sa2.5-3級。搭配安全管理防水防潮電原外接電源插排插孔，便宜作業。搭配調控電原民航外接電源插排插孔便宜作業。獨一無二整潔的防爆調控表面板與電氣控制系統箱。維修與維修保養越來越便宜。車式端蓋形式，防雨罩防爆，手機移動便宜。端蓋門扇使用熱鍵門瑣連接，折裝便宜。手電源開關調控（電氣控制系統DC24V）。一機三用，更具打開式、實業吸砂器、環境型這幾種專用設備的功能鍵。噴砂主機系統利用專項保持線路保護，工作的負擔在0.2Kpa-0.8Kpa位置內隨便調整，可無法有所差異產品工件的噴砂加工過程特殊要求。安全使用位置：除銹防銹、除漆面、焊接件處理（包涵不透鋼304焊口下列不屬于相應的去黑、去焊渣辦理）去刀痕、飛邊、被氧化皮、不透鋼304，鋁材廠家面的風雅型亞光辦理（耐污性很不錯、可遮掩劃破）、去瀝青水泥砂漿土、石雕面污圬等辦理。

Features: Environmental protection cycle recovery type sandblasting machine sets of sandblasting, recycling, circulation, separation, dust removal in a body, no pollution and sand material flying around phenomenon, is a new generation of environmental protection sandblasting equipment. The machine is our company for heavy gush arenaceous job design of multi-purpose, the great work radius, high efficiency of the new environmental protection sandblasting equipment. Root tree produced negative pressure, divided into different device and electric pneumatic two types of all. The equipment adopts compressed air do motive force, abrasive high-speed spray into the surface of workpiece, through the surface of workpiece abrasive impact and remove rust surface, it reaches a certain cleanness and roughness, again through the vacuum pump (or multi-stage vacuum generator) creates negative pressure, recycling waste materials and dust, sand and through the equipment of dust separation system will complete abrasive separation recycling, and continue to dust pollution into the dust collection barrel rust. In hand the switch control, equipment of sandblasting, back to the sand, sand dust separation, sand material circulation, dust filter to complete all action, working environment clean no pollution, work safety to "GB103328-10333 89" workshop air dust health standard. The waste materials, dust the automatic recovery, separation and recycling, the work site clean and free of dust pollution. Environmental protection equipment design, has greatly improved the labor intensity and work environment with blower, can automatically remove dust filter. Built-in water filter. May to the compressed air in secondary water-oil separation. Automatic feeding, will suck sand head into the waste materials, vacuum pump system will start in the automatic feeding. PLC programmable control (optional), material place alarm function (optional). With pressure regulating knobs, counter blowing button. Steady air control device and abrasive valve. Work 20-70 meters radius, surface treatment level of Sa2.5-3 grade. With safety waterproof power socket plug, convenient operation. Configuration control power plug sockets aviation easy operation. Unique beautiful dustproof control panel and the electric. Maintenance and overhaul special convenient. The car type structure, rain dustproof, convenient to move. The cabinet door plank fast door, more convenient to assemble and disassemble zoar connection. The switch control (hand electric control DC24V). One machine with three, with open, industrial suck sand device, environmental protection function of three equipment. Gush arenaceous host machine adopts special control circuit, working pressure in 0.2-0.8 range Kpa Kpa arbitrarily regulate, and can satisfy different requirements of sandblasting process workpiece. Use scope: derusting, except for paint, weld processing (including stainless steel weld and its surrounding the to black, welding slag processing) to deburr, flash, stainless steel, aluminum oxide skin, the elegant type inferior smooth surface treatment (to bear or endure corrupt the gender is good, can cover scratch), to concrete, stone carving surface dirt processing.

◆包括技術性參數設置 Main technical parameters

機械形號 Model	STR-B型無塵自動循環回收式噴砂機
本職工作主機電源 Work power	380V 50HZ
空氣當中各種壓力 Air pressure	5-7kg/cm2
耗氣量 Gas consumption	3m3/min
交流電動機額定功率 Motor power	4kw
工作中有效的施工效率 Work efficiency	6-10m2
運行轉彎半徑 Work radius	10m 可不同消費需求加寬，關鍵服務咨詢客戶
作業手段 Work form	自己無限循環收回Automatic cycle recovery
處理中等級 Clean level	Sa2-3
凹凸不平度 Roughness	60μm以上
權重 Weight	260kg
外觀簡約時尚尺寸大小 Shape dimension	1380×830×1700mm
砂料標準 Sand material specifications	20-100#往上（1.0mm-0.04mm）

◆應用的范圍 Applicable scope

1.的環保要高且無什么凈化裝置的時候；

2.加工級別較高。

1. High environmental protection requirement and without any dust removal equipment occasion;

2. Higher processing level.

安全使用使用范圍：去銹、除乳膠漆焊接縫隙外理去毛刺現象的發生、飛邊、硫化皮304不銹鋼、鋁門窗面上的典雅型亞光治療（耐污性好些、可遮掩割傷）去混疑土、石雕表面層污圬等治療。

（具有素材可參考價值A型或撥打我公司）

Applicable scope: derusting, clean paint processing to weld burr, flash, stainless steel, aluminum oxide skin surface elegant type to bear or endure corrupt processing (matt better properties, can cover scratch) to concrete, stone carving surface dirt processing. (specific information can be A reference type or call our company)

◆ 商品亮點 Product features

此噴砂機戶外工作噴砂無粉塵污染，自動循環回收的環保型設備，我公司研發的C型無塵噴砂機屬于環保型無粉塵噴砂處理機，此機體積已進行壓縮，目地可以說是更方便靈活野外施工過程移動手機更方便靈活，極大程度上的大幅度降低了勞動改造承載力，而且正確處理生產率在中國國內同種型食品靈活；到滿足潛在客戶的不同認為，并已然到了范圍廣的營銷推廣和運行！（重要數據可參考使用A型或呼叫我工司）

features: this machine introduces advanced foreign technology research and development of outdoor work gush arenaceous no dust pollution, automatic cycle recovery of environmental protection equipment. Our company’s C type clean sandblasting machine belong to the most advanced domestic environmental protection no dust gush arenaceous processor, the machine has to minimize, volume compression purpose is convenient outdoor construction convenient to move, greatly reduce the labor intensity, and processing efficiency in domestic products with type fastest; Our customers get a consensus, and has been widely promotion and use! (specific information can be A reference type or call our company)

部份無塵自動循環環保型噴砂機案例:
