管道外壁自動噴砂機
◆符合範圍 Applicable scope
管類產品工件,如:鍍鋅鋼管、槽鋼、拉杠、螺栓、大形柱體、圓罐類、柱體型鋁件;選用雙槍(可按規范多槍)及颶風式除塵設備器和光學光感應特點,增進了生產率及大幅度的減小了修補率。 (此儀器需預先)
The kind of pipe workpieces, such as: steel pipe, round steel, bars, screw, large cylindrical, cylinder, round the plant; Adopt double gun (according to demand more gun) and new filter and light electricity function, improve the production efficiency and reduce the maintenance rate. (the model need to customize)
◆一般技術性性能 Main technical parameters
|
 器機材質 Model  |
 STR-1500管道外壁自動噴砂機  |
 STR-1800輥傳動雙槍自動噴砂機  |
|
 任務艙厚度 Working class size(mm)  |
 1000×900×900  |
 1800×900×1000  |
|
 主機尺寸圖 Complete machine size(mm)  |
 1200×900×2900  |
 1900×900×2900  |
|
 文件壓縮熱空氣源 Compressed air source  |
 2-8bar(kg/cm2)  |
 2-8bar(kg/cm2)  |
|
 24v電源 Power  |
 220v  50Hz   |
 220v  50Hz  |
|
 交流變頻伺服電機調速器器 Governor  |
 250W×2   |
 250W×2  |
|
 脫離器發電機 Separator motor  |
 380v  50Hz  4kw  |
 220v  50Hz  1.1kw  |
|
 脫離器風口尺寸 Air separator  |
 35m3/min  |
 35m3/min  |
|
 廣州POS機重量體積 Machine weight  |
 900kg  |
 900kg  |
